· EGW-CA/SA-25
|
|
|
型号
|
组件尺寸(mm)
|
滑块尺寸(mm)
|
导轨尺寸(mm)
|
油嘴规格
|
基本额定负荷
|
重量
|
|
M
|
W
|
L
|
B
|
C
|
M
|
L1
|
T
|
K
|
N
|
E
|
W1
|
W2
|
M1
|
F
|
di×d2×h
|
C(kN)
|
C0(kN)
|
滑块
kg
|
导轨
kg/m
|
|
EGW-15CA
|
24
|
52
|
56.8
|
41
|
56
|
M5
|
39.8
|
7.2
|
19.7
|
5.5
|
5.5
|
15
|
18.5
|
12.5
|
60
|
(3.5×6×4.5)
4.5×7.5×5.3
|
G-M4
|
7.83
|
16.19
|
0.21
|
1.25
|
|
EGW-15SA
|
24
|
52
|
40.1
|
41
|
-
|
M5
|
23.1
|
7.2
|
19.7
|
5.5
|
5.5
|
15
|
18.5
|
12.5
|
60
|
(3.5×6×4.5)
4.5×7.5×5.3
|
G-M4
|
5.35
|
9.4
|
0.12
|
1.25
|
|
EGW-20CA
|
28
|
59
|
70.1
|
49
|
32
|
M6
|
48.1
|
9
|
22.3
|
6
|
12
|
20
|
19.5
|
15.5
|
60
|
6×9.5×8.5
|
G-M6
|
10.31
|
21.13
|
0.32
|
2.08
|
|
EGW-20SA
|
28
|
59
|
51
|
49
|
-
|
M6
|
29
|
9
|
22.3
|
6
|
12
|
20
|
19.5
|
15.5
|
60
|
6×9.5×8.5
|
G-M6
|
7.23
|
12.74
|
0.19
|
2.08
|
|
EGW-25CA
|
33
|
73
|
83
|
60
|
35
|
M8
|
59
|
11
|
26.8
|
8
|
12
|
23
|
25
|
18
|
60
|
7×11×9
|
G-M6
|
16.27
|
32.4
|
0.59
|
2.67
|
|
EGW-25SA
|
33
|
73
|
59.5
|
60
|
-
|
M8
|
35.5
|
11
|
26.8
|
8
|
12
|
23
|
25
|
18
|
60
|
7×11×9
|
G-M6
|
11.4
|
19.5
|
0.35
|
2.67
|
|
EGW-30CA
|
42
|
90
|
98.1
|
72
|
40
|
M10
|
70.1
|
11
|
32
|
8
|
12
|
28
|
31
|
23
|
80
|
7×11×9
(9×14×12)
|
G-M6
|
23.7
|
47.46
|
1.04
|
4.35
|
|
EGW-30SA
|
42
|
90
|
69.5
|
72
|
-
|
M10
|
41.5
|
11
|
32
|
8
|
12
|
28
|
31
|
23
|
80
|
7×11×9
(9×14×12)
|
G-M6
|
16.42
|
28.1
|
0.62
|
4.35
|
|
EGW-35CA
|
48
|
100
|
108
|
82
|
50
|
M10
|
78
|
14
|
37
|
8.5
|
12
|
34
|
33
|
27.5
|
80
|
9×14×12
|
G-M6
|
33.35
|
64.84
|
1.42
|
6.14
|
|
EGW-35SA
|
48
|
100
|
75
|
82
|
-
|
M10
|
45
|
14
|
37
|
8.5
|
12
|
34
|
33
|
27.5
|
80
|
9×14×12
|
G-M6
|
22.6
|
37.38
|
0.84
|
6.14
|
*导轨安装孔括弧内尺寸需定制
|
· EGH-25CA/SA
|
|
|
型号
|
组件尺寸(mm)
|
滑块尺寸(mm)
|
导轨尺寸(mm)
|
油嘴规格
|
基本额定负荷
|
重量
|
|
M
|
W
|
L
|
B
|
C
|
S
|
L1
|
T
|
K
|
N
|
E
|
W1
|
W2
|
M1
|
F
|
di×d2×h
|
C(kN)
|
C0(kN)
|
滑块
kg
|
导轨
kg/m
|
|
EGH-15CA
|
24
|
34
|
56.8
|
26
|
26
|
M4×6
|
39.8
|
6
|
19.7
|
4.3
|
5.5
|
15
|
9.5
|
12.5
|
60
|
(3.5×6×4.5)
4.5×7.5×5.3
|
G-M4
|
7.83
|
16.19
|
0.15
|
1.25
|
|
EGH-15SA
|
24
|
34
|
40.1
|
26
|
-
|
M4×6
|
23.1
|
6
|
19.7
|
4.3
|
5.5
|
15
|
9.5
|
12.5
|
60
|
(3.5×6×4.5)
4.5×7.5×5.3
|
G-M4
|
5.35
|
9.4
|
0.09
|
1.25
|
|
EGH-20CA
|
28
|
42
|
70.1
|
32
|
32
|
M5×7
|
48.1
|
8
|
22.3
|
5
|
12
|
20
|
11
|
15.5
|
60
|
6×9.5×8.5
|
G-M6
|
10.31
|
21.13
|
0.24
|
2.08
|
|
EGH-20SA
|
28
|
42
|
51
|
32
|
-
|
M5×7
|
29
|
8
|
22.3
|
5
|
12
|
20
|
11
|
15.5
|
60
|
6×9.5×8.5
|
G-M6
|
7.23
|
12.74
|
0.15
|
2.08
|
|
EGH-25CA
|
33
|
48
|
83
|
35
|
35
|
M6×9
|
59
|
8
|
26.8
|
5
|
12
|
23
|
12.5
|
18
|
60
|
7×11×9
|
G-M6
|
16.27
|
32.4
|
0.41
|
2.67
|
|
EGH-25SA
|
33
|
48
|
59.5
|
35
|
-
|
M6×9
|
35.5
|
8
|
26.8
|
5
|
12
|
23
|
12.5
|
18
|
60
|
7×11×9
|
G-M6
|
11.4
|
19.5
|
0.25
|
2.67
|
|
EGH-30CA
|
42
|
60
|
98.1
|
40
|
40
|
M8×12
|
70.1
|
10
|
32
|
7
|
12
|
28
|
16
|
23
|
80
|
7×11×9
(9×14×12)
|
G-M6
|
23.7
|
47.46
|
0.76
|
4.35
|
|
EGH-30SA
|
42
|
60
|
69.5
|
40
|
-
|
M8×12
|
41.5
|
10
|
32
|
7
|
12
|
28
|
16
|
23
|
80
|
7×11×9
(9×14×12)
|
G-M6
|
16.42
|
28.1
|
0.45
|
4.35
|
|
EGH-35CA
|
48
|
70
|
108
|
50
|
50
|
M8×12
|
78
|
12
|
37
|
8
|
12
|
34
|
18
|
27.5
|
80
|
9×14×12
|
G-M6
|
33.35
|
64.84
|
1.13
|
6.14
|
|
EGH-35SA
|
48
|
70
|
75
|
50
|
-
|
M8×12
|
45
|
12
|
37
|
8
|
12
|
34
|
18
|
27.5
|
80
|
9×14×12
|
G-M6
|
22.6
|
37.38
|
0.66
|
6.14
|
*导轨安装孔括弧内尺寸需定制 |
